8 ton mining dumper truck with Four-wheel drive

This rugged 8 ton mining dumper truck tackles challenging terrain with ease. The four-wheel drive system provides superior traction and control on uneven surfaces, while the high ground clearance ensures the truck can navigate obstacles with minimal difficulty. This dependable truck is equipped with a powerful engine and a spacious dump bed, making it ideal for hauling large loads of rock and other quarry materials.

CJY10 Ton Underground Mining Trolley Locomotive

8 ton mining dumper truck with Four-wheel drive

This rugged 8 ton mining dumper truck tackles challenging terrain with ease. The four-wheel drive system provides superior traction and control on uneven surfaces, while the high ground clearance ensures the truck can navigate obstacles with minimal difficulty.  This dependable truck is equipped with a powerful engine and a spacious dump bed, making it ideal for hauling large loads of rock and other quarry materials.

Video



Shipment and site details




shipment and site 5.jpg

shipment and site 3.jpg

shipment and site 7.jpg

shipment and site 6.jpg




Load capacity4 ton5 ton6 ton8 ton10 ton12 ton
Fuel typeDieselDieselDieselDieselDieselDiesel
Motor modelChangchai 490Yunnei 490Yunnei 490Yunnei 4102Yunnei 4102Yunnei 4105
Motor power46KW (63 HP)46KW (63 HP)46KW (63 HP)81KW (110 HP)81KW (110 HP)90KW (122 HP)
Gearbox model530 (12-speed)530 (Twelve high and low speed gears)530 (Twelve high and low speed gears)546 (Twelve high and low speed gears)546 (Twelve high and low speed gears)545 (Twelve high and low speed gears)
Rear axleSL176TDF1069DF1069DF1092DF1092DF1098D
Front axleSL175TSL178SL178SL2059SL2059SL450
Braking systemAir BrakeAir BrakeAir BrakeAir BrakeAir BrakeAir Brake
Rear wheel track1450mm1630mm1630mm1800mm1800mm2150mm
Front wheel track1450mm1630mm1630mm1800mm1800mm1900mm
Wheelbase
2400mm2400mm2620mm2620mm2650mm
Chassis
Main beam: Height 120mm * Width 60mm * Thickness 8mm,
Bottom beam: Height 80mm * Width 60mm * Thickness 6mm
Main beam: Height 120mm * Width 60mm * Thickness 8mm,
Bottom beam: Height 80mm * Width 60mm * Thickness 6mm
Main beam: Height 120mm * Width 60mm * Thickness 8mm,
Bottom beam: Height 80mm * Width 60mm * Thickness 8mm
Main beam: Height 140mm * Width 60mm * Thickness 10mm,
Bottom beam: Height 80mm * Width 60mm * Thickness 8mm
Main beam: Height 200mm * Width 60mm * Thickness 10mm,
Bottom beam: Height 80mm * Width 60mm * Thickness 8mm
Unloading methodRear unloadingRear unloading, double 800mm hydraulic jacksRear unloading, double 800mm hydraulic jacksRear unloading, double 110mm hydraulic jacksRear unloading, double 110mm hydraulic jacksRear unloading, double 110mm*950mm hydraulic jacks
Front tire model650-16 steel wire tire700-16 mining tire700-16 mining tire750-16 mining tire825-16 mining tire825-16 mining tire
Rear tire model700-16 steel wire tire (dual)700-16 mining tire (double tire)700-16 mining tire (double tire)750-16 mining tire (double tire)825-16 mining tire (double tire)825-16 mining tire (double tire)
D imensionsL*W*H : 3950mm*1450mm*1330mmL*W*H : 4900mm*1630mm*1400mmL*W*H : 4900mm*1630mm*1400mmL*W*H : 5200mm*1800mm*1750mmL*W*H : 5400mm*1800mm*1750mmL*W*H : 5100mm*2150mm*1750mm
Cargo dimensionsL*W*H : 2400mm*1330mm*450mmL*W*H : 3100mm*1600mm*500mmL*W*H : 3100mm*1600mm*500mmL*W*H : 3400mm*1750mm*750mmL*W*H : 3600mm*1750mm*750mmL*W*H : 3400mm*2100mm*750mm
Cargo plate thicknessBottom 8mm, Side 5mmBottom 10mm, Side 5mmBottom 10mm, Side 5mmBottom 10mm, Side 5mmBottom 10mm, Side 5mmBottom 10mm, Side 6mm
Steering wheelHydraulic Power SteeringHydraulic Power SteeringHydraulic Power SteeringHydraulic Power SteeringHydraulic Power SteeringHydraulic Power Steering
Cargo volume1.6 m32.2 m32.2 m34.3 m34.7 m35 m3
