Light Rails for mining construction

Production Introduction The rail is composed of three parts: head, web, and feet. In order to make the guide rail better bear various forces and ensure the necessary strength conditions, the guide rail should have sufficient height, the size and heig

CJY10 Ton Underground Mining Trolley Locomotive
Production Introduction
The rail is composed of three parts: head, web, and feet. In order to make the guide rail better bear various forces and ensure the necessary strength conditions, the guide rail should have sufficient height, the size and height of its head and feet should be large enough, and the thickness of the web and feet should not be too thin.






Hot Tags:

No Information

No Information

Productos relacionados
Name Model Sectional Dimension(mm) Theoretical weight
Height Bottom Width Head Width Web Thickness
Light Rail 8Kg/m 65.00 54.00 25.00 7.00 8.42
12Kg/m 69.85 69.85 38.10 7.54 12.20
15Kg/m 79.37 79.37 42.86 8.33 15.20
18Kg/m 90.00 80.00 40.00 10.00 18.06
22Kg/m 93.66 93.66 50.80 10.72 22.30
24Kg/m 107.00 92.00 51.00 10.90 24.46
30Kg/m 107.95 107.95 60.33 12.30 30.10
Heavy Rail 38Kg/m 134.00 114.00 68.00 13.00 38.733
43Kg/m 140.00 114.00 70.00 14.50 44.653
50kg/m 152.00 132.00 70.00 15.50 51.514
60Kg/m 176.00 150.00 73.00 16.50 60.800
75Kg/m 192.00 150.00 75.00 20.00 74.640
UIC54 159.00 140.00 70.00 16.00 54.430
UIC60 172.00 150.00 74.30 16.50 60.210
Lifting Rail QU70 120.00 120.00 70(76.5) 28.00 52.8
QU80 130.00 130.00 80(87) 32.00 63.69
QU100 150.00 150.00 100(108) 38.00 88.96
QU120 170.00 170.00 120(129) 44.00 118.1
