5 Ton Lithium Battery Mining Locomotive

By adopting the Lithium Battery Power supply, the locomotive is easy to operate, and long service life, also Maintenance-free Our 5 Ton Battery Locomotive use the most stableLithium Iron Phosphate cells, which can be applieed in the gold mining, zinc

CJY10 Ton Underground Mining Trolley Locomotive
By adopting the Lithium Battery Power supply, the locomotive is easy to operate, and long service life, also Maintenance-free
Our 5 Ton Battery Locomotive use the most stable Lithium Iron Phosphate cells, which can be applieed in the gold mining, zinc mining and other places without explosion gas.
The Max carring capacity is about 50 ton( on the 3‰ slope)


Locomotive Avantage Please ClickLocomotive Advantages.

Operation Video


Model CTY5/679G(B)
Total-weight 5t
Track gague 500600762 or 900mm
Tracktion force 7.06kN
Max traction 12.26kN
Speed 7km/h
Battery device Voltage 90V
Capacity 385Ah
Motor power 7.5 kW×2
dimensions Lenght 3170mm
Width 9201082 or 1220mm
Height 1550mm
Wheel base 850mm
Wheel diameter Φ520mm
Min turn radius 6m
Controlling way Resistence or IGBT
Brake way Mechnical brake or hydraulic
