3.5 Ton Battery Locomotive(CTY3.5/6GB)

3.5 Ton battery locomotive is special desgined for our South America clients it could be equiped with hydraulic brake method. The loading capacity is about 35 Ton ores including the self weight of locomotive and wagons. The application of 3.5Ton bat

CJY10 Ton Underground Mining Trolley Locomotive

3.5 Ton battery locomotive is special desgined for our South America clients it could be equiped with hydraulic brake method.
The loading capacity is about 35 Ton ores including the self weight of locomotive and wagons.

The application of 3.5Ton battery locomotive
The underground electric locomotive will transport the ore (waste rock) discharged from the stope hopper stope patio or chute to the underground storage bin the bottom (or middle section) car yard or directly out of the mine through the flat tunnel Transport the materials and equipment from the depot at the bottom of the well (or the middle section) to the work site.

Locomotive Avantage Please Click: Locomotive advantages





Shipment and one site details


5t battery locomotive 1.jpg

shipment and site 11.jpg

shipment and site 14.jpg

shipment and site 10.jpg

shipment and site 8.jpg





5-ton battery locomotive 29.jpg

Model CTY3.5/679G(B)
Total-weight 3.5t
Track gague 500600762 or 900mm
Tracktion force 7.06kN
Max traction 12.26kN
Speed 7km/h
Battery device Voltage 90V
Capacity 385Ah
Motor power 7.5 kW×2
dimensions Lenght 3170mm
Width 9201082 or 1220mm
Height 1550mm
Wheel base 850mm
Wheel diameter520mm
Min turn radius 6m
Controlling way Resistence or IGBT
Brake way Mechnical brake or hydraulic
